1. High-end configurations: crucial components and parts are globally advanced brands.
2. High working efficiency, stronger digging force and lower fuel consumption.
3. Humanized design, convenient for maintenance and has lower use cost.
4. The vehicle has a high safety level: FOPS cab is equipped with guardrail, emergency shutdown switch, alarm lamp and camera, etc.
5. Automatic lubrication system is a standard configuration that reduces grease injection time and increases working efficiency.
Operating weight: 115000kg
Bucket capacity: 6.0 m3 rock/ 7.0 m3 soil.
Engine: CUMMINS QSK23, 567KW/1800rpm
Torque: 3468N.m; Displacement: 23.15L
Bucket digging force； 597KN
Arm crowd force: 470kN;
Max. traction : 746kN
Travel speed: 3.3/2.0km/h
Gradeability: 30%
Max. digging radius: 13860mm
Max. digging height: 12500mm
Max. dumping height: 7990mm
Max. digging depth: 8110mm
Max. Vertical wall digging depth: 5390mm
8-inch horizontalplane digging depth: 7990mm
Min. swing radius: 6770mm
Length of boom: 7550mm
Length of arm: 3400mm
Width of platform: 3450mm
Length of crawler: 6500mm
Width of crawler: 700mm
Min. ground clearance: 1070mm
Hight of crawler: 1710mm
Dimension: 14610x5470x6160mm
